Thank you for choosing this Icom product. This
product is designed and built with Icom's state of the
art technology and craftsmanship. With proper care,
this product should provide you with years of trouble-
free operation.

IMPORTANT

READ ALL INSTRUCTIONS carefully and completely
before using the transceiver.
SAVE THIS INSTRUCTION MANUAL— This
instruction manual contains basic operating
instructions for the IC-7760. For advanced operating
instructions, see the Advanced manual for details.
The Advanced manual is available at the following
internet address:
https://www.icomjapan.com/support/

FEATURES

• RF Direct Sampling System
The IC-7760 employs an RF direct sampling
system. RF signals are directly converted to digital
data in the ADC, and then processed in the FPGA.
This system is a leading technology, marking an
epoch in amateur radio.
• The separate configuration
The IC-7760 consists of the controller and the RF
deck.
• 2 identical receivers and speakers
The IC-7760 has 2 independent receiver circuits
and speakers for the Main and Sub bands.
• A built-in DIGI-SEL unit
Both the Main and Sub receivers have built-in
DIGI-SEL (digital preselector) units. These reject
interfering signals.
• Real-Time Spectrum Scope
Displays the Main and Sub band conditions. It
provides class-leading performance in resolution,
sweep speed and provides a 100 dB dynamic
range.
• 2 touch panel color displays
• A built-in automatic antenna tuner
• Multi-function control for easy settings
• Digital Pre-Distortion (DPD) function that
reduces the distortion of the SSB and AM mode
signals
• I/Q baseband signal output port
• IP remote control capability with the optional
RS-BA1 Version 2 ip remote control software
• Remote encoder capability with the optional
RC-28 remote encoder
• Dualwatch operation

SUPPLIED ACCESSORIES

Desktop stand
Assembled screws
(M3 × 12 mm)
CW key plugs
( 3.5 mm: 1/8 inch stereo)
ACC plug ACC plug
(7-pin) (8-pin)
L Some accessories are not supplied, or the shape is
different, depending on the transceiver version.

TRADEMARKS

Icom and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United
States, the United Kingdom, Germany, France,
Spain, Russia, Australia, New Zealand, and/or other
countries.
All other products or brands are registered trademarks
or trademarks of their respective holders.
This product includes RTOS "RTX" software, and is
licensed according to the software license.
This product includes "zlib" open source software, and is
licensed according to the open source software license.
This product includes "libpng" open source software, and
is licensed according to the open source software license.
This product includes "mbed TLS" open source software,
and is licensed according to the open source software
license.
Refer to the "About the Licenses" page at the end of the
manual in English for information on the open source
software being used in this product.
About weld lines
This product's surfaces may have streaks called
"weld lines," that occur during the molding process,
and are not cracks or flaws.
i
Power adapter for Controller
(1.8 m: 5.9 ft)
Power cable for RF deck
(2 m: 6.6 ft)
Control cable
(3 m: 9.8 feet)
