SET MODE

DPD Adjustment

» SET > DPD Adjustment
MENU
IC-7760 Single Adjustment
Displays the screen for selecting the band for the DPD
single adjustment and checking the adjustment status
of each band is displayed.
IC-PW2 Linked Adjustment (200V)
Displays the screen for selecting the band for the DPD
linked adjustment with the IC-PW2 at 180 ~ 264 V AC
and checking the adjustment status of each band at
1 kW or 500 W output is displayed.
L The adjustment starts at the maximum output power
selected on the IC-PW2.
L If the IC-PW2 is not connected, the previous DPD linked
adjustment status will be displayed.
L Before performing the DPD linked adjustment, the DPD
single adjustment must be completed.
IC-PW2 Linked Adjustment (100V)
Displays the screen for selecting the band for the DPD
linked adjustment with the IC-PW2 at 90 ~ 132 V AC
and checking the adjustment status of each band at
500 W output is displayed.
L If the IC-PW2 is not connected, the previous DPD linked
adjustment status will be displayed.
L Before performing the DPD linked adjustment, the DPD
single adjustment must be completed.

Connectors

» SET > Connectors > Phones
MENU
Level
Sets the audio output level ratio of the headphones
and internal speaker between -15 and +15.
L/R Mix
Selects to output the mixed audio from the
headphones or to output the Main band's audio from
the left side and the Sub band's audio from the right
side.
L/R Mix Level
When "L/R Mix" is set to "ON," sets the mixed level of
the Main and Sub band's audio.
MENU

Output Select

Selects the signal output from the [USB B] port on the
controller's rear panel.
• AF: An AF signal is output.
• IF:
AF/IF XFC Output (SPLIT ON)
Selects the signal output from the [USB B] port on the
controller's rear panel while holding down
operation.
AF Output Level
Sets the AF output level of the [USB B] port on the
controller's rear panel, when "Output Select" of USB is
set to "AF."
AF SQL
Selects whether or not to output the audio from the
[USB B] port on the controller's rear panel, depending
on the squelch state, when "Output Select" of USB is
set to "AF."
• OFF (Open): The squelch is always open,
• ON:
AF Beep/Speech... Output
Sets the Beep and Speech audio output setting of
the [USB B] port on the controller's rear panel, when
"Output Select" of USB is set to "AF."
• OFF: The beep and speech audio are not output.
• ON: The beep and speech audio are output.
IF Output Level
Sets the IF output level of the [USB B] port on the
controller's rear panel, when "Output Select" of USB is
(Default: 0)
set to "IF."
(Default: ON)
(Default: 70%)
8-9
» SET > Connectors > USB AF/IF Output
A 12 kHz IF signal is output.
(Default: OFF (Open))
regardless of the transceiver's
squelch level.
The squelch opens and closes,
according to the transceiver's squelch
level.
(Default: AF)
(Default: SUB)
in split
XFC
(Default: 50%)
(Default: OFF)
(Default: 50%)
