Setting the frequency

D Directly entering a frequency

You can set the frequency without rotating
by directly entering it using the keypad.
Entering the operating frequency on the Sub
screen
1. Push several times to display the
SUB DISP
Keypad screen.
2. Touch [F-INP].
• Opens the Tenkey pad.
3. Start entry with the most significant digit.
Sub screen
Main screen
L To clear the entry, touch [CE].
L To clear the entry and return to the previous screen,
push SUB DISP .
4. Touch [ENT] to set the entered frequency.
• Returns to the Band keypad.
L If you touch [ENT] when the digits under 100 kHz are
not entered, "0" will be automatically entered into the
digits that are blank.
Entry examples
• 14.025 MHz: [1], [4], [•(−)], [0], [2], [5], [ENT]
• 18.0725 MHz: [1], [8], [•(−)], [0], [7], [2], [5], [ENT]
• 730 kHz: [0], [•(−)], [7], [3], [ENT]
• 5.1 MHz: [5], [•(−)], [1], [ENT]
• 7 MHz: [7], [ENT]
MAIN DIAL
Band keypad
SUB DISP
3-6
Entering the operating frequency on the Main
screen
1. Touch the MHz digits. (Example: 21)
• Opens the BAND STACKING REGISTER screen.
2. Touch [F-INP].
• Opens the F-INP screen.
3. Start entry with the most significant digit.
L To clear the entry, touch [CE].
L To clear the entry and return to the previous screen,
push .
EXIT
4. Touch [ENT] to set the entered frequency.
• Closes the F-INP screen.
L If you touch [ENT] when the digits under 100 kHz are
not entered, "0" will be automatically entered into the
digits that are blank.
• Changing from 21.28 MHz to 21.245 MHz:
[•(−)], [2], [4], [5], [ENT]
L Touching [•(−)] first enters the same MHz digits as the
operating frequency.
