Icom IC-7760 Basic Manual page 61

RF/SQL Control
Set the AF RF/SQL (outer) control operation.
L See the Advanced manual for details.
Cancel CI-V Remote Set Levels
While remotely controlling the transceiver, sent CI-V
commands override some of the control dials' setting
values.
Select whether or not to overwrite all control dial's
setting values (such as the AF Volume dial with a
mark on it) by their position if one of them on the
transceiver is rotated.
• All Volume Levels:
All dials' setting values are overwritten by their
position, even if one of them is rotated.
• Operated Volume Level:
Only the rotated dial's setting value is
overwritten by its position.
» SET > Function > TX Power Limit
MENU
1.8M
1.8M (DATA)
3.5M
3.5M (DATA)
5M
5M (DATA)
7M
7M (DATA)
10M
10M (DATA)
14M
14M (DATA)
18M
18M (DATA)
21M
21M (DATA)
24M
24M (DATA)
28M
28M (DATA)
50M
50M (DATA)
Sets the power limit to between 2 W and 200 W for
each selected band.
L The maximum output power from an antenna connector
to which the AH-730 optional antenna tuner is connected
is limited to 100 W.
(Default: RF+SQL)
(Default: All Volume Levels)
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
(Default: 200W (AM: 50W))
» SET > Function > TX Delay
MENU
HF
50M
Sets the TX delay time on each band.
L If an external equipment's rise time is slower than that
of the IC-7760, a reflected wave is produced, and it may
damage the IC-7760 or the external device. To prevent
this, set the appropriate delay time so that no reflected
wave or timing damage occurs.
L Select "OFF" for no delay.
SEND
Rx
Tx
Po
» SET > Function
MENU
Time-Out Timer (CI-V)
Sets the Time-out Timer for CI-V operation to OFF,
3, 5, 10, 20, or 30 minutes to prevent an accidental
prolonged transmission.
This setting is valid only for transmitting initiated by a
CI-V command or pushing
L Select "OFF" for no time limit.
Quick Dualwatch
Turns the Quick Dualwatch function ON or OFF by
holding down
DUAL-W
» SET > Function > SPLIT
MENU
Quick SPLIT
Turns the Quick SPLIT function ON or OFF.
This function automatically turns ON the SPLIT
function, and sets the frequency and mode according
to the SPLIT Offset setting.
• OFF: Turns OFF the function.
• ON: Turns ON the function.
Display Keypad on Quick SPLIT
In the SSB, CW, RTTY, PSK, or AM mode, selects
whether or not to display the F-INP screen by holding
down for 1 second.
SPLIT
FM SPLIT Offset (HF)
FM SPLIT Offset (50M)
In the FM mode, sets the SPLIT offset between
–9.999 and +9.999 MHz.
The SPLIT offset is the difference between the receive
and transmit frequencies for the Quick SPLIT function.
8-4
SET MODE
(Default: OFF)
(Default: OFF)
Delay time (ms)
0 10
(Default: OFF)
.
TRANSMIT
(Default: ON)
for 1 second.
(Default: ON)
(Default: OFF)
(Default: –0.100 MHz)
(Default: –0.500 MHz)
8
8
