No. Component
11 Grounding stud
12 Asset tag
13 Ground for ESD-preventive wrist strap
1.3.2

LEDs

Table 1-5 LEDs
Silkscreen
Label
SYS
BMC
FAN
LED Description
○
○
System status ○
LED
○
○
○
BMC status
LED
Fan status
Solid green: The system is operating normally.
Blinking green: The system is starting up.
Solid red: The system (including all modules) is not
functioning properly.
At least two power or fan modules are not installed.
At least two power modules are not connected with the
AC power cord.
The temperature exceeds the limit and the switching
service resets.
Solid yellow:
The temperature reaches the threshold.
A power or fan module is not installed.
A power module is not connected with the AC power
cord.
Off: The system is not receiving power or not operating
even after receiving power.
Solid green: The BMC module is operating normally.
Blinking green: The BMC module is starting up.
Off: The BMC module is not connected or not functioning
properly after being connected.
Solid green: The fan module is operating normally.
