IPC962/IPC964 Series User's Manual
2.4

Installing the Fan Module and PCI or PCIe Card

IPC962-511-FL/IPC962-512-FL/IPC964-512-FL provides two/four PCI or PCIe slots for
expansion. The procedure of installing the Fand module and PCI / PCIe expansion card into
system is instructed below.
Step 1 Completed the fan module as below procedure.
(IPC962 series)
→
(IPC964 sereis)
Step 2 Turn off the system.
Step 3 Disconnect the power connector.
Step 4 Unscrew the thumbscrew and separating the cover from the expansion box.
42
→
→
--
→
Hardware Installation
