Overview

Meter mode allows you to view real-time meter data. The metered parameters available
Introduction
are logically separated into Standard and Distortion tabs. Meter screens are displayed in
tabular form.
NOTE: Meter mode operation does not interfere with any of 4400's other monitoring
or recording functions. The individual voltage and current channel meter readings are
not affected by the monitoring setup. Turning monitoring of individual channels off
does not affect meter readings. Meter and Scope data is NOT available if you are
viewing a stored file from the data card.
The 4400 is designed to provide setup as well as data display. Metered parameters are
Metered
parameters
available for display regardless if they are being journalled under Setup New Circuit >
display
Advanced Options > Journal Limit Setup. Users can trend journal entries by limits
(Very High, High, Low, Very Low) or by time (users can set the time interval of how
often rms and waveform snapshots will be recorded even when no disturbances occur).
For the procedure on how to set entries under journal parameters, go to Chapter 6
Advanced Setup Options - Journal Limit on page 6-15.
The following topics are covered in this section.
In this section
Standard Meter Tab
Distortion Meter Tab
Section B
Meter Mode
Topic
CH 3/ View Real Time Data
See Page
3-6
3-8
3-5
