Overview

The 4400 allows users to view power quality phenomena as it happens, when it
Introduction
happens. The instrument is able to capture and process data in real time, and allows
users to view it in Scope mode, Meter mode, Harmonics, and Phasor display.
Icons for Scope mode, Meter mode, Harmonics, and Phasor display are available in the
Access to real
time data
Home screen. Follow these steps to display the Home screen.
Action...
STEP 1: Press the 4400 On/Off
power button to turn the unit on.
The Home screen will be
displayed.
This chapter is divided into four sections.
In this chapter
C H A P T E R
View Real Time Data
Section
A Scope Mode
B Meter Mode
C Harmonics
D Voltage and Current Phasor
3
Result...
Title
MARK001b
See Page
3-2
3-5
3-10
3-15
3-1
