General - Dranetz DBPGFLEX3KPKG User Manual

General

General
Size: 12" Width x 2.5" Height x 8" Depth (30 x 6.4 x 20.3 cm)
Dimensions
Weight: 3.8 pounds
Operating: 0 to 50 °C (32 to 122 °F)
Environmental
Storage: -20 to 55 °C (4 to 131 °F)
Humidity: 0 to 95% non-condensing; indoor use
Altitude: 2000 m (6560 ft) maximum
Crystal controlled; 1 second resolution
System Time
Clock
Event time clock displays to 1 msec resolution
Time displayed in analog or digital (12 or 24 hour) format
Accurate to 60 seconds per month
Sizes range from 32MB to 128MB
Compact Flash
Data Card
Use ONLY the external power supply provided with the unit for operation and battery
Power
Requirements
charging. Use of any other power supply is not recommended.
Voltage: 90-264V AC, 45-66 Hz
Consumption: 20 watts maximum
Field replaceable batteries: More than 2 hours run-time (3 hours typical) when fully
charged.
Input resistance Voltage input: 16 MΩ Line to Line
Current input: 400 kΩ
B-2
