Panel Operation
The annunciator panel displays metered data for the selected parameter. The metered
Annunciator
panel color
data is updated once per second. This is the same data that appears in the meter screen,
scheme
and used in calculating journals. If the selected parameter is not journalled, the rms
event or transient event count can be selected to appear in the panel instead of
journalled data.
Disabled parameters appear in gray. A panel is considered disabled if none of the limits
were set.
Enabled parameters, on the other hand, are color-coded. A panel is active while the
instrument is monitoring or by loading a previously saved file from the data card. An
active panel can have two or three states (Normal, Moderate, or Severe). When
monitoring, parameters that are within limits are shown in green (indicates Normal
state). Those that are moderately out of limits, exceeding Low or High threshold limits,
are shown in yellow (indicates Moderate state). Parameters that are extremely out of
limits, exceeding Very Low or Low threhold limits, are shown in blinking red
(indicates Severe state).
Users may choose to plot a parameter since the panel is linked to the plot screen.
Annunciator
panel links
Simply select the parameter if you want to view it in detail. Use View Graph to display
the parameter plot and use View Limits to view the parameter threshold values.
The properties of a panel can also be customized. Use Edit Panel to enable/disable
channels to plot.
The next pages
The same procedure applies even when you select different journal categories to plot.
show how to view a parameter in detail using the annunciator panel.
CH 8/ Reports
8-19
