Overview

Data files (.ddb) consist of events that are saved to the data card while monitoring is on.
Introduction
The 4400 allows users to load stored data directly from card.
The following topics are covered in this section.
In this section

Loading Data from Card

Card Error Messages
Follow these steps to load data from card.
Loading data
from card
Action...
STEP 1: From the Start Menu,
press Load data from card. The
4400 lists the data files (.ddb)
stored in card, along with file
size, time and date when the data
files were recorded. Data files are
arranged in the order of date and
time they were recorded.
• Press Up/Down arrow keys to
scroll the page up or down by
one line.
• Press to select (highlight) the
desired data file.
• Press OK to load data from
card to the 4400 and return to
Home screen.
• Press Cancel to quit and return
to Start Menu.
If an error message is displayed, refer to Card Error Messages on page 5-36.
NOTE
Section E
Load Data from Card
Topic
Result...
CH 5/ Start Menu
See Page
5-35
5-36
MARK140pg
5-35
