4400 Controls, Indicators, and Connectors

4400 is a self-contained, portable instrument weighing less than 4 pounds and
Dimensions
measuring 8" (20.3 cm) deep by 12" (30.5 cm) wide by 2.5" (6.4 cm) high. This section
identifies and describes the controls, indicators, and connectors on all panels of the
4400 shown with rubber boot installed.
Top View

Front View

Rear View

Bottom View

S L O T 1
S L O T 2
CH 1/ Getting Started
1-5
