- Page 1 PR150/SP1B PR150/SP2B PR1500/SP7B PR1500/SP8B AC/DC CURRENT PROBES 5 Commonwealth Ave 5 Commonwealth Ave 5 Commonwealth Ave 5 Commonwealth Ave Woburn, MA 01801 Woburn, MA 01801 Woburn, MA 01801 Woburn, MA 01801 Phone 781-665-1400 Phone 781-665-1400 Phone 781-665-1400 Phone 781-665-1400 Toll...
- Page 2 No part of this book may be reproduced, stored in a retrieval system, or transcribed in any form or by any means—electronic, mechanical, photocopying, recording, or otherwise—without prior written permission from the publisher, Dranetz, Edison, NJ 08818-4019. Printed in the United States of America. P/N 899216 Rev C 08.20.12...
- Page 3 ADVERTENCIA Una conexión incorrecta de este instrumento puede producir la muerte, lesiones graves y riesgo de incendio. Lea y entienda este manual antes de conectar. Observe todas las instrucciones de instalación y operación durante el uso de este instrumento. La conexión de este instrumento a un sistema eléctrico se debe realizar en conformidad con el Código Eléctrico Nacional (ANSI/NFPA 70-2011) de los E.E.U.U., además de cualquier otra norma de seguridad correspondiente a su establecimiento.
- Page 4 AVERTISSEMENT Si l'instrument est mal connecté, la mort, des blessures graves, ou un danger d'incendie peuvent s'en suivre. Lisez attentivement ce manuel avant de connecter l'instrument. Lorsque vous utilisez l'instrument, suivez toutes les instructions d'installation et de service. Cet instrument doit être connecté conformément au National Electrical Code (ANSI/NFPA 70-2011) des Etats-Unis et à...
- Page 5 WARNUNG Der falsche Anschluß dieses Gerätes kann Tod, schwere Verletzungen oder Feuer verursachen. Bevor Sie dieses Instrument anschließen, müssen Sie die Anleitung lesen und verstanden haben. Bei der Verwendung dieses Instruments müssen alle Installation- und Betriebsanweisungen beachtet werden. Der Anschluß dieses Instruments muß in Übereinstimmung mit den nationalen Bestimmungen für Elektrizität (ANSI/NFPA 70-2011) der Vereinigten Staaten, sowie allen weiteren, in Ihrem Fall anwendbaren Sicherheitsbestimmungen, vorgenommen werden.
-
Page 6: Safety Precautions
SAFETY PRECAUTIONS The following safety precautions must be followed whenever any type of voltage or current connection is being made to the instrument. When connecting to electric circuits or pulse initiating equipment, open their related breakers. DO NOT install any connection of the instrument on live power lines. - Page 7 INTRODUCTION These user instructions provide descriptive and operational information about the optional PR150/SP1B, PR150/SP2B, PR1500/SP7B and PR1500/SP8B current probes. The PR150/SP1B, PR150/SP2B, PR1500/SP7B and PR1500/SP8B current probes have been designed for accurate non-intrusive measurement of AC and DC current. The PR150/SP1B, PR150/SP2B, PR1500/SP7B and PR1500/SP8B conform to the latest directives concerning safety and electromagnetic compatibility.
-
Page 8: Connection Procedure
Employee Workplaces (ANSI/NFPA 70E-2012) of USA and any additional workplace safety requirements applicable to your installation. Always refer to the applicable User’s Guide for additional information concerning installation, operation, and connections of Dranetz or Original Equipment Manufacturer’s instructions applicable to your installation. -
Page 9: Safety Warning
OPERATING INSTRUCTIONS Refer to Figure 1 and Figure 2. 1. Switch On (PR150/SP1B and PR1500/SP7B) Connect the external power supply to the probe via the 2.1 mm jack socket, switch on the power source and check that the LED on the handle of the probe is lit. - Page 10 5. Current measurement Connect the output lead to a multimeter. Select the AC or DC mV range on the multimeter as appropriate to the current measurement. If necessary adjust the probe output voltage to zero as described in Step 4. Clamp the jaws of the probe round the conductor ensuring a good contact between the closing faces of the jaws.
-
Page 11: Battery Supply
( - terminal) ( + terminal) Note: Use of non-Dranetz accessories may be susceptible to noise influencing current measurements and use of one adapter to power 4 probes is not recommended. Each probe should be... - Page 12 FIGURE 1...
- Page 13 FIGURE 2...
-
Page 14: Specifications
SPECIFICATIONS Electrical Data – PR150/SP1B and PR150/SP2B (All accuracies stated at 23°C ± 1°C) Nominal Current In 150 A DC and AC Measuring Range ± 200 A Overall accuracy (at 23°C) ± 1% of rdg (10% to 120%) ± 2% max. - Page 15 Electrical Data – PR1500/SP7B and PR1500/SP8B (All accuracies stated at 23°C ± 1°C) Nominal Current In 1500 A DC and AC Measuring Range ± 1800 A Overall accuracy (at 23°C) ± 1% of rdg (10% to 120%) ± 2% max. Resolution ±...
-
Page 16: Scale Factors
SCALE FACTORS Probe Model Number Range Scale Factor PR 150 150A PR 1500 1500A 1000... - Page 17 All products of Dranetz are warranted to the original purchaser against defective material and workmanship for a period of one year from the date of delivery. Dranetz will repair or replace, at its option, all defective equipment that is returned, freight prepaid, during the warranty period.
