Interfaces

Mains supply: Installation Category II, Pollution Degree 2
Installation
Categories
Measurement inputs: Installation Category III, Pollution Degree 2
Type: 1/4 VGA color graphic, touch screen Liquid Crystal Display (LCD) with
Display
compact fluorescent (CCFL) backlighting. Programmable backlight time-out to reduce
power consumption. Reactivates with touch.
Resolution: 360 x 240 dot matrix
Size: 3.75 x 4.75 inches
Audible alarm of short (approximately 0.1 second) or long (approximately 1 second)
Alarm
duration to call attention to an error condition or event trigger, respectively.
Communication Connect to the 4400 mainframe using either of the following interface adapter:
• RS232 - Fiber Optic adapter
• USB - Fiber Optic adapter
• LAN - Fiber Optic adapter
APPENDIX B/ Technical Specifications
B-3
