Overview

Overview
The event screen displays actual voltage or current waveforms that occurred when a
What is
displayed?
certain threshold parameter was crossed. Event activity graphs, event list, waveform
display, rms display, and time plots are visually interfaced showing event patterns and
behaviors over threshold limits and time. The event screen also enables users to
customize data plots, allowing users to change and/or add parameters/channels for each
of the four plot areas. Zoom box features, wherein users can expand or narrow the size
of a zoomed area via touch and drag, are also available for more thorough data analysis
and interpretation. Users can select the number of waveform and rms cycles to view, as
well as display event textual summary as shown on pages 7-9 thru 7-13.
The following topics are covered in this section.
In this section
Event Data Display
Event Activity Graph
Event List
Event Detail
Event Options
7-4
Section A
Events
Topic See Page
7-5
7-6
7-7
7-9
7-14
