Turning Channels On/Off

From the Scope mode screen, press Chan to turn Volts/Amps channel selection on/off.
Select channels
to display
Any of the following will turn channels on/off:
• Press the desired Volts/Amps channel to turn it on/off.
• Press Volts or Amps button to turn on/off all channels of that parameter.
• Press A, B, C, D to turn on/off both the Volts and Amps for that channel.
Press OK to accept channel selection.
CH 3/ View Real Time Data
MARK202
3-3
