Data Analysis Features

All about Markers

All about Markers
Markers move along the X-axis range of the measurement trace to provide a
numerical readout of each measured data point. Markers also allow you to
search for specific Y-axis values.
A trace can contain up to six markers.
The marker readout on the FieldFox screen displays X and Y-axis information
for the current active marker ONLY.
A Marker Table can be displayed that allows you to simultaneously view X and
Y-axis information for all markers.
Markers can be used in CAT, NA, SA, and Pulse Measurements Modes.

How to create Markers

— Press Marker.
— Then
— Then
— Then move the marker using the rotary knob, the
— Then press Enter.

How to move a Marker after it is created

— Press Marker.
— Then
— Then move the marker as when it was first created.
— Markers can also be moved using one of the marker search functions. Learn
16- 2
Markers 1...6 to select a marker to activate.
Normal to activate that marker. A marker is created on the trace in the
middle of the X-axis. That marker is now active.
entering an X-axis position with the number keys.
Markers 1...6 repeatedly until the marker of interest is selected. The
OFF, Normal, or Delta softkey is black to indicate the current setting of
each marker.
more in "Searching with Markers" on page
arrows, or by
16-7.
