Keysight Technologies N99xxA Series Quick Start Manual

THANK YOU
N9 9 x x A / B FieldFox Ha ndheld A naly zer
Congratulations, with this instrument you will achieve fast, accurate results with confidence.
IMPORTANT!
FULLY charge the FieldFox battery before using the FieldFox for the first time (i.e, The battery will
be fully charged in about 4 hours).
When setting FieldFox on a surface, it is recommended to operate it with the kickstand open. The
cooling is less effective when FieldFox is placed lying down flat on the instrument's back.
-
Learn more or for questions: Download the
N9927-90001 or N9938-90003 User's Guide.
-
See also, www.keysight.com/find/fieldfox.
Step 1
1. Install the battery pack into the FieldFox
battery compartment. The battery door is
located on the lower-right side of the FieldFox
(i.e., Press and slide the door down to open).
For more, see Step 3.
Power connector
Audio jack
DC VoltageSource
Quick S t ar t Guide
Step 2
2. Insert the supplied AC/DC adapter (15-19 VDC) into the power connector and
into an electrical outlet (AC/DC adapter is not shown).
- N9912A and N9923A models: The power connector is located on the right side,
under the middle hinged door.
- All other models: The power connector is located on the LEFT side, under the
bottom hinged cover.
Step 3
3. Extend the
kickstand and
press the power
button.
Power button
LED
