N9030B PXA Signal Analyzer
Option RTS, Streaming
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement
business has become Keysight Technologies. For more
information, go to
.
www.keysight.com
Installation Note

Advertisement

loading

Related Manuals for Keysight Technologies N9030B

Summary of Contents for Keysight Technologies N9030B

  • Page 1 Keysight Technologies N9030B PXA Signal Analyzer Option RTS, Streaming Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement business has become Keysight Technologies. For more information, go to www.keysight.com Installation Note...
  • Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3 Introduction This installation note explains how to install Real Time Streaming (Option RTS) hardware and license onto the N9030B signal analyzer. This kit is not to be used on the N9030A. Hard ware Requirements These options must be previously installed: •...
  • Page 4 — 5/16-inch torque wrench — 9/16-inch open-end wrench — Keysight Calibration and Adjustment Software, N7814A (revision E.16.00 or later) — Test equipment and computer supported by the Keysight Calibration and Adjustment Software — N9030B Signal Analyzer Service Guide. Installation Note N9030-90087...

  • Page 5: Initial Instrument Functionality Check

    Option RTS, Streaming Initial Instrument Functionality Check Power on the instrument and allow the instrument to boot up, run the alignments and display the measurement screen. The instrument will probably display a spectrum analyzer screen and you will see the instrument sweeping. There should be no alignment failures.

  • Page 6: Hardware Installation

    Option RTS, Streaming Hardware Installation 1. Power down the instrument, wait until the standby light comes on, and remove the power cord. 2. Remove the instrument side strap handles, feet, outer case, top brace, and right side chassis (RF side bracket). Save all screws for reuse. 3.
  • Page 7 Option RTS, Streaming 5. Again, starting at the attenuator near the back of the instrument, push the end of the second flex cable that does not have the locator pins behind both attenuators. This cable will route next to the attenuators and on the outside of the flex cable previously installed. The cable will route between the frame and the small ribbon cable, and through the opening in the instrument frame where the second Wideband Digital IF is located in motherboard slot 7.
  • Page 8 Option RTS, Streaming Install the WBDIF Extension board and Bracket 1. Locate the WBDIF Extension board and the bracket in the kit. Attach the WBDIF Extension board to the bracket with four screws from the kit. See Figure 2. Torque to 9 inch-pounds. 2.
  • Page 9 Option RTS, Streaming 3. On the rear panel, remove the label covering the two connector slots. 4. Position the WBDIF Extension board near the right side rear of the instrument. See Figure Locate the flex cable that is attached to the Wideband Digital IF board in slot 5. Insert this flex cable into the WBDIF Extension board J1 connector.
  • Page 10 Option RTS, Streaming Complete Hardware Installation 1. Replace the RF side cover. Install one of the screws from the kit through the side cover and into the WBDIF Extension board bracket. 2. Replace the top brace. When installing the top brace assure cables do not get smashed under the top brace.

  • Page 11: License Installation Procedure Over Usb

    Option RTS, Streaming License Installation Procedure over USB 1. Locate the Option Upgrade Entitlement Certificate (5964-5178) from the kit. 2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the Certificate. 3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an attached License File.
  • Page 12 2. Press System, Show System to display a list of installed options. 3. Verify that the installed options list contains the newly installed N9030B-RTS. 4. Press System, Show Hard ware. Verify there is an entry for the WB DIF Extension assembly.
  • Page 13 This information is subject to change without notice. © Keysight Technologies 2016 Edition 1, June 2016 N9030-90087 www.keysight.com...
