Connecting To An Mcu - Polycom MGC-100 Getting Started Manual

Connecting to an MCU

Initial IP
Configuration
Installing the
MGC Manager
Starting the MGC
Manager
Defining an MCU
Connecting
to an MCU
Configuring the
Network Services
Once the MCU connection parameters are defined, the MGC Manager can be
connected to all defined MCUs simultaneously. The MGC Manager allows
you to set up conferences, make reservations, monitor On Going Conferences
and perform other activities on several MCUs. The MGC Manager reports the
status of each MCU connection.
To connect the operator workstation to an MCU:
1. In the Browser pane, double-click the MCUs Network icon, or expand the
MCUs Network icon.
A list of MCUs appears below the MCUs Network icon.
2. Double-click the MCU icon.
Alternatively, right click the MCU icon to which you want to connect,
and then click Connect.
The Logon dialog box opens.
3. Enter your Login Name and Password, and then click OK.
Note that each MCU is initially configured with a default operator whose
Login and Password are both POLYCOM. Additional operators can be
defined. For more details, see the MGC Administrator's Guide,
Chapter 6.
Chapter 3 - Initial System Configuration
3-9
