Assigning Network Services To The Ip/Ip+ Cards - Polycom MGC-100 Getting Started Manual

MGC-50/MGC-100 Getting Started Guide

Assigning Network Services to the IP/IP+ Cards

3-58
For each IP card installed in the MCU, you need to define which Network
Service is used, thereby defining the network properties connected to that
card. Usually, one Network Service is used for all IP cards, enabling the MCU
to automatically manage the conferencing resources.
The association between the network properties and the IP cards is done in
two stages. In the first stage, while defining the IP Network Service, you add
all the IP cards that can use this Network Service (they are all using the same
IP network entities such as gatekeeper, DNS, SIP server or DHCP). In the
second stage, you define for each IP card which Network Service it uses to
manage conferencing calls.
For SIP conferences, or conferences that include SIP participants, IP+
cards from version 4.23 or higher are required. For H.323-only
conferences, IP (12 or 24) cards are sufficient.
To assign IP service settings to the IP card:
1. In the Browser area, expand the MCU tree.
2. Expand the MCU Configuration tree.
3. Expand the Cards tree.
