Hardware Description
This chapter describes the various components that make up the MGC unit.
The following components are described:
•
Main Control Module
Backplane
•
Power Supply Module
•
Fans
•
Alarms port
•
Functional Modules
•
— ISDN/T1-CAS Net-2/4/8
— IP/IP+ cards
— MUX
— MUX+
— Audio+12/24, Audio+24/48, Audio+48/96
— Standard Video
— Video+
— Data
Input/Output cards
•
2
2-1
