Chapter 2 - Hardware Description

MGC-50 Components Location

2-6
Figure 4-6 shows the front panel of the MGC-50. The front panel provides
access to the Main Control Module, the Functional Modules, and the Power
Supply Module. Status LEDs on the Main Control Module, Functional
Modules, and Power Supply Module indicate the status of the system.
Main
Control
Module
CONT
Critical
POLYCOM
Major
Minor MGC-50
L0
Power
L1
L2
L3
PWR
OUT
Floppy Disk Drive
COM Port
Figure 2-5: MGC-50 front panel
Functional Modules
Ejectors
LEDs
PRI-8 MG-323
AUDIO AUDIO VIDEO VIDEO VIDEO
Stby Stby Stby Stby Stby Stby Stby
Fail Fail Fail Fail Fail Fail Fail
Active Active Active Active Active Active Active
Line 1
Line 2
Line 3
Line 4
Line 5
Line 6
Line 7
Line 8
VIDEO
Stby
Fail
Active
