Polycom MGC-100 Getting Started Manual page 43

7. Click Next.
The PRI Settings dialog box opens.
8. In the PRI Settings dialog box, define the following parameters:
Table 3-2: PRI Settings Dialog Box Options
Field
Default num-type
Num-plan
Voice
Chapter 3 - Initial System Configuration
Description
The num-type defines how the system handles the
dialing digits. If you want the network to interpret the
dial digits for routing the call, select Unknown.
For video conferencing purposes, select the ISDN
option.
Indicate the frequency of the data being sent. For
practical purposes, the Voice option is set to 3.1
KHz as it is the more widely used frequency.
3-13
