When the Cards icon in the Browser pane is double-clicked, the Status
pane displays the status of the card.
Occupied slots appear in green while empty slots appear in grey. The slot
number appears next to the slot icon. Table 4-2 describes the Status pane
columns.
Table 8-2: MCU's Cards Status Columns
Field
Slot
Type
Description
Displays the slot icon and number; a grey icon
indicates an empty slot and a green icon indicates
an occupied slot.
Displays the type of card that occupies the slot. The
following card types are available, as listed in Table
4-1:
•
Network (Net-2, Net-4, Net-8, MPI-4, MPI-8),
IP+12, IP+24, IP+48
•
MUX+
•
Data
• Audio+
• Video+
Chapter 8 - Management Tools
8-9
