Power Source

© Polycom, Inc. 2003
V.35/RS-449/RS-530 network interface:
V.35/RS-449/RS-530 module
•
Optional cables used to connect the V.35/RS-449/RS-530
•
module to the DCE:
(V.35 "Y" cable (HD-44M to DB-25M/RS-366 and M34
–
"Winchester" V.35 )
– RS-449/422 "Y" cable (HD-44M to DB-25M/RS-366 and
DB-37M/RS-449/422)
Ascend cable (HD-44M to HD-44M)
–
These cables are available from the Polycom Web store.
Access to your Data Communications Equipment (DCE) or
•
Data Service Unit (DSU).
Quad BRI network interface:
• Quad BRI Inverse Multiplexer (IMUX)
4 RJ-45 cables
•
– 1 RJ-45 cable with a keyed connector
– BRI line ordered from your service provider
The ViewStation EX system has an external power supply. It
supports line voltages between 100V and 240V and line frequencies
from 47 Hz to 63 Hz.
You void the warranty and may possibly damage your system if
you do not use the provided power supply.
Chapter 2 - Installing the ViewStation EX
Note
Warning
31
