ViewStation EX User Guide

Setting up the Quad BRI Network Interface

38
V.35/RS-449/RS-530 Cable Adapter Kit. You can also purchase an
additional cable adapter kit (available through your reseller) to
extend the distance between your system and the
V.35/RS-449/RS-530 network interface module.
V.35/RS-44/RS-530 and RS-366 Connections. The
V.35/RS-449/RS-530 connection on the V.35 cable is used for data
and the RS-366 connection is used for dialing. If you plan to place 2
x 56 Kbps or 2 x 64 Kbps calls, use one cable for each port.
If your DCE does not use dialing, do not use the RS-366 (DB-25M)
connector.
LED Information. Refer to the V.35/RS-449/RS-530 Technical
Information section of the Integrators' Reference Manual for
ViewStation EX, ViewStation FX, and VS4000.
This section explains how to install and connect the Quad BRI
network interface module so that you can make calls over ISDN
with the ViewStation EX system.
To connect the Quad BRI network interface module to the
system:
Make sure your system is turned off.
1.
Find the cable with the light blue RJ-45 keyed connector on one
2.
end and the green RJ-45 (non-keyed) connector on the other
end.
Insert the light blue RJ-45 keyed connector into the light blue
3.
RJ-45 keyed port on the back of the system.
4. Insert the green (non-keyed) RJ-45 connector into the green
RJ-45 port labeled
Note
xon the network interface module.
