Figure 7-1.Lan & Intranet Screen - Polycom ViewStation EX User Manual

© Polycom, Inc. 2003
b. Insert the other end of the cable into a port on the LAN. This
connection is shown in the QuickStart.
2. To connect the PC to the system:
a. Insert one end of the provided blue RJ-45 cable into the blue
PC port on the back of the system.
b. Insert the other end of the cable into the Ethernet port on
your computer.
Power on the system.
3.
Select System Info > Admin Setup > LAN/H.323 >
4.
LAN/Intranet to configure the system's LAN/H.323 settings.
The LAN & Intranet screen appears.
Figure 7-1. LAN & Intranet Screen
5. In the LAN & Intranet screen, configure the system DHCP
settings, as follows:
Chapter 7 - Using the System with a PC
221
