ViewStation EX User Guide

Setting up the ViewStation EX

34
To connect your cables and equipment to the back of the
ViewStation EX system:
1. Place the system on top of the television monitor with the front
lip overhanging the top of the television monitor.
2. Place the microphone pod on a flat surface between the meeting
participants and the television monitors. Do not place the
microphone pod near the television monitor speakers.
Connecting and disconnecting the microphone off the system does
not require a reboot of the system.
3. Connect the required equipment and cables to the back of your
system as shown in the QuickStart.
Connect any optional equipment to the back of your system as
4.
shown in the QuickStart. Optional equipment can include a PC,
VCR, telephone, audio mixer, document camera, XGA projector
or monitor, Visual Concert FX, or additional television
monitors.
The colors on the cables match the colors on the back of the
system panel.
5. To prevent cable entanglement, wrap the enclosed cable tie
around all of the cables.
6. Put the batteries in the remote control.
You are now ready to set up your network interface. See
Network Interface Modules, on page 35
Note
Note
for additional information.
