[Adjust Printer]
[Auto Head Adj.]
[Manual Head Ad]
[Auto Band Adj.]
[Manual Head Adj]
[Adjust Length]
[Head Inc. Adj.]
Setting Item
[Standard Adj.]
[Advanced Adj.]
[Auto Print]
[Standard Adj.]
[Advanced Adj.]
[A:High]
[B:Standard/Draft]
T-1-22
Description/Instructions
Choose Yes to have the printer print and read a test pattern for the automatic adjustment of
Printhead alignment relative to the printing direction.
Choose Yes to have the printer print and read a test pattern for the automatic adjustment of
Printhead alignment relative to the nozzle and printing direction.
Choose On to have the printer automatically execute the Advanced Adj. operations after you
replace the Printhead.
Choose Yes to print a test pattern for adjustment of Printhead alignment relative to the printing
direction. Enter the adjustment value manually based on the resulting pattern.
Choose Yes to have the printer print and read a band adjustment test pattern for automatic
adjustment of the feed amount.
Choose this option when using paper other than genuine Canon paper, or paper for purposes
other than checking output.
Choose Yes to have the printer print and read a band adjustment test pattern for automatic
adjustment of the feed amount. Note that this function takes more time and requires more ink
than Standard Adj.
Choose Yes to print a test pattern for adjustment of Printhead alignment relative to the printing
direction. Enter the adjustment value manually based on the resulting pattern.
Choose Yes to print a test pattern for adjustment relative to paper stretching or shrinkage, after
which you can enter the amount of adjustment.
Select [Yes] to print an adjustment pattern for adjusting the inclination of the printhead.
