Chapter 1
[GL2 Settings]
[Quality Manager]
[Paper Manager]
[Line & Pen Manager]
[ProcessingOption]
1-38
Setting Item
[Color Mode] [Monochrome]
[Color (CAD) 1]
[Color (CAD) 2]
[Color (CAD) 3]
[Color (CAD) 4]
[Color (CAD) 5]
[Color (CAD) 6]
[Print Quality]
[Input Resolution]
[Print (Economy)]
[Paper Source]
[Margin]
[Conserve Paper]
[Auto Rotate]
[Nesting] [Use Nesting]
[Nesting WaitTime]
[Cut Lines]
[Enable merge]
[Pen Setup] [Select Palette]
[Define Palette]
[Reset Palette]
[Smoothing]
[ThickenFineLines]
[AdjustFaintLines]
[Warning]
[On-the-Fly]
[PageSizeProcess1]
[PageSizeProcess2]
T-1-21
Description/Instructions
Print by the monochrome.
Print by the standard color.
Print by the bright color.
Print by the color emulated the Canon iPF500/iPF600/iPF700/
iPF510/iPF610/iPF710/iPF605/iPF720/iPF810/iPF820.
Print by the color emulated the HP Designjet 500/800.
Print by the color emulated the HP Designjet 1000.
Print by the color emulated the HP Designjet 4000/4050.
Select the print quality.
Choose the printer input resolution from between [600dpi] and
[300dpi].
Prints with a lower grade of print than normal, but with less ink
consumption. Select [ON] to economize on inks.
Select how to feed paper for printing on the HP-GL/2.
Set the top/bottom and left/right margins of the paper. For cut-
sheet, the trailing edge margin is 23mm.
However, if the leading edge margin is set with [Paper Details],
that value has priority.
Prints by economizing on paper.
If a document has its long side shorter than the roll width, the
page rotates by 90 degrees automatically to economize on paper.
If a document contains horizontally long data such that it has its
long side longer than the roll width and its short side shorter than
the roll width, the page rotates 90 degrees to print within the
boundaries of the paper.
HP RTL cannot rotate.
In case of HP RTL image, the image may be truncated or a blank
paper may be ejected because the image cannot be rotated even
if the paper size is rotated by 90 degrees. In that case, set [Auto
Rotate] to [Off].
Select [On] to print pages when they are tiled fully to the roll
width, instead of printing them one by one.
Set the time to elapse before printing.
Select [On] to print perforated lines between pages.
When lines overlap, set whether to merge or overwrite the colors
of the overlapping lines.
Select [Off] to overwrite with the line printed later. Select [On]
to merge all overlapping colors.
Select the value related to pen from [Software], [Palette A],
[Palette B], or [Factory].
Select [Software] to print according to the application side
instruction. Select [Palette A] or [Palette B] to print with value
set by [Define Palette].
Set [Width], [Color], and [Line Attributes] for the palette's [Pen
Number]. Select [Factory] to check the value when [Factory] is
selected for [Select Palette].
For [Line Attributes], select the shape of line end and joint
between lines as [No Setting] or [Circle Setting].
Return the [Define Palette] settings to factory settings.
Choose whether to draw an arc with a smooth curve or with a
polygon.
Select [On] to print thin lines clearly.
If thin lines print in a tint of color varied from other patterns,
selecting [Off] may provide the print result as intended, though
the thin lines may print, interrupted, depending on the color.
Select [On] to display warnings during GL2.
In printing data consisting solely of HP RTL, if the data is slow
to print, select [On] to expedite the time at which the data starts
printing. Verify the print result to make sure that images are not
chipped in this case.
Normally, an image is printed inside margins necessary for
printing, but if the image data itself has margins, the print
position will not be offset when this is set [On].
Select [On] to determine the paper size based on the drawing
area.
