Canon imagePROGRAF iPF815 Service Manual page 281

Code
Panel display
(last 4 digits)
(Large LCD)
- Media take-up unit
ready.
Online: Print
Stop: Stop Printing
- End of paper feed.
Cannot feed
paper more.
- Close Ink Tank
Cover
- The roll feed unit
is loose. Push it
all the way in.
- Prepare for parts
replacement.
Call for service.
- Parts replacement
time has passed.
Call for service.
1000 Ink Level: Check
to
Not much ink is
100C
left. Prepare to
replace the ink.
100F End of paper feed.
Cannot feed
paper any more.
1010 Problem with
Printhead L/R
Chk printing results
Check printed
document.
1012 Problem with
Printhead R
Chk printing results
1013 Problem with
Printhead L
Chk printing results
1015 This type of paper
is not compatible
with HP-GL/2.
1021 Papr Type Mismatch
1022 Papr Type Mismatch
Panel display
Explanation/Detection sequence
(Small LCD)
Media take-up unit use has been set to [Do
not use] at the start of printing when the
media take-up unit is active.
Feed Limit.. Forced feed limit
Paper being manually fed in the return
direction (back-feeding) has reached the
pinch roller position.
Ink tank cover open while printing
On a model having a subtank, the ink tank
cover opened while printing. (Printing is
allowed to continue.)
The roll unit has been pulled out during
standby or printing on the lower roll paper
or cut sheet A3 or less.
W Level 1 Durable parts replacement due soon
Any of the parts counters has reached
Consumables Low
warning level 1.
W Level 2 Durable parts replacement due soon
Any of the parts counters has reached
Repl Consumables
warning level 2.
Ink Lvl: Chk XX Ink tank near-empty (continued use
allowed)
The remaining volume of ink is
diminishing (below the pin check level).
(XX: Target color display)
Last 2 digits of error code:
00:Bk, 01:Y, 02:M, 03:C, 04:PM, 05:PC,
06:MBk1, 07:MBk2, 08:GY, 09:PGY,
0A:R, 0B:B, 0C:G
End of paper feed. The limit of forced paper feeding. The
media reached to a pinchroller at feeding
backfeed media manually.
(not an error or a failure)
CheckPrintout:LR Head non-ejection warning (Check
printout/ possible to continue printing)
See 280C for detection criteria.
Check Printout
CheckPrintout:R Printhead R non-ejection warning (double-
head model)
(Check printout/ possible to continue
printing)
See 280C for detection criteria.
CheckPrintout:L Printhead L non-ejection warning (double-
head model)
(Check printout/ possible to continue
printing)
See 280C for detection criteria.
GL2: Unsup. papr HP-GL2 error: out of the scope of paper
support
GL2: Incompatible paper
[Warning Indication] or [Pause] have been
type
selected for [Paper Mismatch Detection].
Press Online Starts printing
The paper that is being fed does not support
HP-GL/2 printing; that is, a paper type that
does not have a required print mode has
been set.
MediaType Mismatch Paper mismatch (type)
With [Warning Indication] is selected for
[Paper Mismatch Detection], the type of
loaded paper mismatches the specified
type. Or, with [Pause] is selected for [Paper
Mismatch Detection], the [Online] button
was pressed to execute forced printing.
MediaType Mismatch Paper mismatch (type)
With [Warning Indication] is selected for
[Paper Mismatch Detection], the type of
loaded paper mismatches the specified
type. Or, with [Pause] is selected for [Paper
Mismatch Detection], the [Online] button
was pressed to execute forced printing.
Chapter 8
Remedial Action
1. Press the [Online] button to set the
media take-up unit use setting to force
[Use] and print.
2. Press the [Stop] key to cancel
printing.
The message clears automatically 2
seconds later.
Check the Paper detection sensor/
Media sensor sensor (I/O mode).
The message clears when the ink tank
cover is closed.
Check the sensor (I/O mode).
Close the roll unit.
Check the parts counter and prepare
the target unit or Refresh Service Kit.
Initialize the parts counter for the
target unit after the replacement.
1. Replace the tank (continued usage
allowed).
2. If the problem persists after the tank
has been replaced, the remaining ink
detection system is at fault. (Replace
the supply unit or check catching wire
or connection status of harness.)
The message is cleared automatically
after displaying for 2sec.
Confirmation of Paper detection
sensor/ Media sensor sensor (I/O
mode)
1. Check image quality. (Unless there
are problems with the image quality,
there is no need to replace the
printhead.)
2. Replace the printhead.
When [Warning Indication] is selected
Replace with appropriate paper.
When [Pause] is selected
1. Press the [Online] button to force
printing.
Caution) Due to use of image process
table (LUT) defined for HP-GL/2
compatible paper different from the
specified paper, you might have a
problem in quality of image.
2. Press the [Stop] button to cancel
printing.
Continued printing is allowed.
Check driver setting.
Replace with appropriate paper.
Continued printing is allowed.
Check driver setting.
Replace with appropriate paper.
8-3
