Canon imagePROGRAF iPF815 Service Manual page 230

Chapter 6
J4001
Pin Number Signal name
A11 SPOOL_ENCB
A12 N.C
A13 N.C
A14 N.C
B1 RGV19(VM_26V_2)
B2 YOBITOKYUUIN_FAN_ALA
RM_2
B3 GND
B4 RGV8(SNS3V)
B5 GND
B6 /CUTTERM_SNS_L
B7 CUTTERM_AM
B8 CUTTERM_AP
B9 RGV17(VM26V)
B10 DCOVER_L
B11 RGV17(VM26V)
B12 SPOOL_CL_1OUT
B13 RGV17(VM26V)
B14 SPOOL_CL_2_OUT
J3150
Pin Number Signal name
1 IN 3-
2 IN 3+
3 IN 1+
4 IN 2-
5 IN 1-
6 IN 2+
7 VM_GND
8 +5V
9 OUT B
10 OUT B
11 OUT A
12 OUT A
13 OUT C
14 OUT C
J2801
Pin Number Signal name
1 OUT_LFSP_A
2 OUT_LFSP_VM
3 OUT_LFSP_AB
4 OUT_LFSP_BB
5 OUT_LFSP_VM
6 OUT_LFSP_B
J4101
Pin Number Signal name
A1 /OP_DACCHAKU_R_IN
A2 /OP_DACCHAKU_L_IN
A3 OP_KYUUSHI_UNIT
A4 OP_FLAPPER_SOL
A5 OP_PICKUP_CL
A6 OP_KYUUSHI_CL
A7 GND
A8 GND
A9 RGV19(VM_26V_2)
A10 RGV19(VM_26V_2)
A11 GND
A12 RGV29(UMF5V)
A13 OP_SPOOL_ENCA_IN
6-8
IN/OUT Function
- N.C
- N.C
- N.C
- N.C
OUT Power supply(+26V)
BP maintenance jet suction fan alarm signal
- GND
OUT Power supply(+3.3V)
- GND
IN Cutter left position sensor output signal
OUT Cutter motor drive signal AM
OUT Cutter motor drive signal AP
OUT Power supply(+26V)
OUT Upper cover lock solenoid (L) drive signal
OUT Power supply(+26V)
OUT Roll media rewinding clutch drive signal
OUT Power supply(+26V)
OUT Roll media pick-up roller clutch drive signal
T-6-22
IN/OUT Function
IN Hole sensor input signal 3-
IN Hole sensor input signal 3+
IN Hole sensor input signal 1+
IN Hole sensor input signal 2-
IN Hole sensor input signal 1-
IN Hole sensor input signal 2+
- GND
OUT Power supply (+5V)
OUT Motor output signal B
OUT Motor output signal B
OUT Motor output signal A
OUT Motor output signal A
OUT Motor output signal C
OUT Motor output signal C
T-6-23
IN/OUT Function
OUT Feed motor drive signal A
OUT Power supply(+32V)
OUT Feed motor drive signal AB
OUT Feed motor drive signal BB
OUT Power supply(+32V)
OUT Feed motor drive signal B
T-6-24
IN/OUT Function
IN Lower roll unit release detection switch (R) output signal
IN Lower roll unit release detection switch (L) output signal
- GND
OUT Lower flapper solenoid drive signal
OUT Lower roll media pick-up cam clutch drive signal
OUT Lower roll media pick-up roller clutch drive signal
- GND
- GND
OUT Power supply(+26V)
OUT Power supply(+26V)
- GND
OUT Power supply(+26V)
- N.C
