Canon imagePROGRAF iPF815 Service Manual page 240

Chapter 6
J103
Pin Number Signal name
43 H1-C-DATA-4-OD
44 GND
45 MLT_SENS_1IN
46 GND
47 MLT_SENS_2IN
48 GND
49 SNS5V
50 GND
J102
Pin Number Signal name
1 /H1-E-HE-8
2 GND
3 H1-E-DATA-8-OD
4 GND
5 H1-E-DATA-9-OD
6 GND
7 /H1-F-HE-10
8 GND
9 H1-F-DATA-10-OD
10 GND
11 H1-F-DATA-11-OD
12 GND
13 /H1-F-HE-11
14 GND
15 H1-F-DATA-11-EV
16 GND
17 H1-F-DATA-10-EV
18 GND
19 /H1-E-HE-9
20 GND
21 H1-E-DATA-9-EV
22 GND
23 H1-E-DATA-8-EV
24 GND
25 /H1-D-HE-7
26 GND
27 H1-D-DATA-7-EV
28 GND
29 H1-D-DATA-6-EV
30 GND
31 /H1-D-HE-6
32 GND
33 H1-D-DATA-6-OD
34 GND
35 H1-D-DATA-7-OD
36 GND
37 H1-C-DATA-5-OD
38 GND
39 /H1-C-HE-5
40 GND
41 H1-C-DATA-5-EV
42 GND
43 H1-C-DATA-4-EV
44 GND
45 /H1-B-HE-3
46 GND
47 H1-B-DATA-3-EV
48 GND
49 /LIFT CAM IN
50 GND
6-18
IN/OUT Function
OUT Odd head(L) data signal 4(C)
- GND
IN Multi sensor signal 1
- GND
IN Multi sensor signal 2
- GND
OUT Power supply(+5V)
- GND
T-6-37
IN/OUT Function
OUT Head(L) heat enable signal 8(E)
- GND
OUT Odd head(L) data signal 8(E)
- GND
OUT Odd head(L) data signal 9(E)
- GND
OUT Head(L) heat enable signal 10(F)
- GND
OUT Odd head(L) data signal 10(F)
- GND
OUT Odd head(L) data signal 11(F)
- GND
OUT Head(L) heat enable signal 11(F)
- GND
OUT Even head(L) data signal 11(F)
- GND
OUT Even head(L) data signal 10(F)
- GND
OUT Head(L) heat enable signal 9(E)
- GND
Even head(L) data signal 9(E)
- GND
OUT Even head(L) data signal 8(E)
- GND
OUT Head(L) heat enable signal 7(D)
- GND
OUT Even head(L) data signal 7(D)
- GND
OUT Even head(L) data signal 6(D)
- GND
OUT Head(L) heat enable signal 6(D)
- GND
OUT Odd head(L) data signal 6(D)
- GND
OUT Odd head(L) data signal 7(D)
- GND
OUT Odd head(L) data signal 5(C)
- GND
OUT Head(L) heat enable signal 5(C)
- GND
OUT Even head(L) data signal 5(C)
- GND
OUT Even head(L) data signal 4(C)
- GND
OUT Head(L) heat enable signal 3(B)
- GND
OUT Even head(L) data signal 3(B)
- GND
- GND
- GND
