Canon imagePROGRAF iPF815 Service Manual page 233

J3401
Pin Number Signal name
1 VMGND
2 VMGND
3 VMGND
4 VMGND
5 VH_MONI1
6 VH_ENB
7 VH_MONI2
8 GND
9 +3.3V
10 +3.3V
11 GND
12 SNS5V
13 SNS5V
14 VM
15 VM
16 VM
17 VM
18 VM
19 VM
20 VM
21 VM
22 VMGND
23 VMGND
24 VMGND
25 VMGND
T-6-27
IN/OUT Function
- GND
- GND
- GND
- GND
IN VH controll signal 1
OUT VH power supply ON/OFF signal
IN VH controll signal 2
- GND
OUT Power supply(+3.3V)
OUT Power supply(+3.3V)
- GND
OUT Power supply(+5V)
OUT Power supply(+5V)
OUT Power supply(+32V)
OUT Power supply(+32V)
OUT Power supply(+32V)
OUT Power supply(+32V)
OUT Power supply(+32V)
OUT Power supply(+32V)
OUT Power supply(+32V)
OUT Power supply(+32V)
- GND
- GND
- GND
- GND
Chapter 6
6-11
