Canon imagePROGRAF iPF815 Service Manual page 226

Chapter 6
J1202
Pin Number Signal name
3 GND
J1801
Pin Number Signal name
1 AFCONT
2 VM_ENB
3 VMGND
4 VMGND
5 VM
6 VM
7 GND
8 GND
9 GND
10 RGV20(+5V)
11 RGV20(+5V)
12 RGV20(+5V)
J2402
Pin Number Signal name
1 VM_26V
2 MISTFAN_L_ALARM
3 MISTFAN_L_PWM
4 GND
J2501
Pin Number Signal name
1 PUMPM1_AM
2 PUMPM1_AP
3 GND
4 PUMPR_ENCA
5 RGV31(SNS5V_FU)
6 PUMPR_ENCB
7 RGV8(SNS3V)
8 GND
9 /CONTROL_CAM_R
10 RGV8(SNS3V)
11 GND
12 /LIFT_CAM
13 RGV8(SNS3V)
14 GND
15 /CR_HP
16 OUT_LIFTM_VM
17 OUT_LIFTM0_A
18 OUT_LIFTM2_AX_N0
19 OUT_LIFTM1_B
20 OUT_LIFTM3_BX_N1
J2601
Pin Number Signal name
1 POWER_ON
2 GND
3 RGV20(+5V)
4 BUZZER
5 PDO
6 +3.3V
7 PDI
8 HDD_LED
9 /PRESET
10 GND
6-4
IN/OUT Function
- GND
T-6-4
IN/OUT Function
OUT Normal/Power saving switch signal
OUT VM enable signal
- GND
- GND
IN Power supply(+32V)
IN Power supply(+32V)
- GND
- GND
- GND
IN Power supply(+5V)
IN Power supply(+5V)
IN Power supply(+5V)
T-6-5
IN/OUT Function
OUT Power supply(+26V)
OUT Mist fan(L) alarm signal
OUT Mist fan(L) duty control signal
- GND
T-6-6
IN/OUT Function
OUT Purge motor drive signal AM
OUT Purge motor drive signal AP
- GND
IN Pump encoder output signal A
OUT Power supply(+5V)
IN Pump encoder output signal B
OUT Power supply(+3.3V)
- GND
IN Pump cam sensor output signal
OUT Power supply(+3.3V)
- GND
IN Lift cam sensor output signal
OUT Power supply(+3.3V)
- GND
IN Carriage HP sensor output signal
OUT Power supply
OUT Lift motor drive signal A
OUT Lift motor drive signal AX
OUT Lift motor drive signal B
OUT Lift motor drive signal BX
T-6-7
IN/OUT Function
IN Power switch signal
- GND
OUT Power supply(+5V)
OUT Buzzer control signal
OUT Panel IC control signal
OUT Power supply(+3.3V)
OUT Panel IC data signal
OUT HDD lamp control signal
OUT Panel reset signal
- GND
