Canon imagePROGRAF iPF815 Service Manual page 289

Code
Panel display
(last 4 digits)
(Large LCD)
2570 Ink insufficient.
to Press OK and
257C replace ink tank.
2580 Ink insufficient.
to Press OK and
258C replace ink tank.
Ink insufficient.
Replace ink tank.
2590 Ink insufficient.
to Press OK and
259C replace ink tank.
(*1)
Ink insufficient.
Replace ink tank.
259C Ink insufficient.
(*2) Press OK and
to replace ink tank.
25A8
Ink insufficient.
Press OK and
replace ink tank.
25B7 Close the ink tank
cover. Unable to detect ink
level correctly.
Unable to detect ink level
correctly.
260E Hardware error.
03130031-260E
Turn off printer,
wait, then
turn on again.
260F Gap error.
Turn off printer.
2618 Hardware error.
03130031-2618
Turn off printer,
wait, then
turn on again.
Panel display
Explanation/Detection sequence
(Small LCD)
Ink tank short on ink
A suction operation was attempted, but
there is not enough ink left in the tank for
the operation (iPF8000 series, iPF9000
series).
Reference)
About 5 mL to 40 mL of ink may have been
left in the tank when this warning occurs.
70:Bk, 71:Y, 72:M, 73:C, 74:PM, 75:PC,
76:MBk1, 77:MBk2, 78:GY, 79:PGY,
7A:R, 7B:B, 7C:G
Not Enough Ink Ink tank short on ink
(lower arrow) A suction operation was attempted, but
Replace ink tank there is not enough ink left in the tank for
orOnline to prnt the operation.
(In the small LCD, the lower arrow points
to the color in question.)
Reference)
About 5 mL to 40 mL of ink may have been
left in the tank when this warning occurs.
80:Bk, 81:Y, 82:M, 83:C, 84:PM, 85:PC,
86:MBk1, 87:MBk2, 88:GY, 89:PGY,
8A:R, 8B:B, 8C:G
Not Enough Ink Ink tank short on ink
(lower arrow) A print operation was attempted, but there
Replace ink tank is not enough ink left in the tank for the
orOnline to prnt operation.
(In the small LCD, the lower arrow points
to the color in question.)
Reference)
About 5 mL to 40 mL of ink may have been
left in the tank when this warning occurs.
90:Bk, 91:Y, 92:M, 93:C, 94:PM, 95:PC,
96:MBk1, 97:MBk2, 98:GY, 99:PGY,
9A:R, 9B:B, 9C:G
(*1) 259C: 03810208-259C
Ink insufficientPress (lower Ink insufficient in inktank.
arrow) key. The amount of ink left in the inktank is
Replace inktank or start insufficient for printing. (In the small LCD,
printing online. the lower arrow points to the
correspondence color.)
Reference)
There are the cases that about 5ml to 40ml
ink is left in a inktank at warning occurs.
9C:Bk,9D:C,9E:M,9F:Y,A0:PC,A1:PM,A
2:MBk1,A3:MBk2,
A4:GY,A5:PGY,A6:R,A7:G,A8:B
(*2) 259C: 03810104-259C
The remaining ink falls below the pin
check level while ink tank cover is open.
Power On Gap detection failure
Again Carriage gap calibration has not been
Gap Detect Err carried out, or gap detection is disabled by
corrupt calibration data.
Power On Gap reference plane error
Again Request to replace an abnormal reference
Gap Error plane sheet (only in Service mode).
Vh voltage error
Chapter 8
Remedial Action
1. Replace the tank.
2. Failure of remaining ink detection
system.
(Replace the supply unit /check the
bundled wires.)
1. Replace the ink.
2. Failure of remaining ink detection
system.
(Replace the supply unit /check the
bundled wires.)
1. Replace the ink.
2. Failure of remaining ink detection
system.
(Replace the supply unit /check the
bundled wires.)
1. Replace inktank
2. Failure of detecting the ink amount
left in the inktank.
(Replace the supply unit /check the
bundled wires.)
Close the ink tank cover.
Note) It does not recover if the cover is
open when replacing the ink tank with
a valid one.
If removing the ink tank with lower ink
remains (LIR) than Supply Pin in this
situation, an error is detected.
Also when keeping printing in this
situation, if empty subtank
corresponding to the ink tank with LIR
is detected, the error shifts from ink
tank with LIR to empty subtank.
1. Check to see if the multisensor
reference plate (white patch for batch
correction) is not soiled and perform
GAP CALIB (if soiled, adjust the part
after replacing it).
2. Replace the multisensor and
perform GAP CALIB.
3. Replace the carriage unit and
perform GAP CALIB.
Check the multisensor reference plate
(for soiling and faulty mounting).
8-11
