Chapter 8
Code
(last 4 digits)
2E1B The roll is empty.
Load/Eject: Change Paper
The roll is empty.
Lift the release
lever and replace
the roll.
The roll is empty.
The roll is empty.
Lift the release
lever and replace
the roll.
Out of roll paper.
Push the release
lever back, then
replace the roll.
2E1C Paper jam.
Press Load/Eject
and reload the
paper.
2E1D Cannot load.
Press Load/Eject
and reload the
paper.
2E1F Cannot print
as specified.
Press Load/Eject
and replace paper with A2/
16.6"x23.4"
(vertical) or larger
Cannot print as specified.
Press Load/Eject and
replace roll with 10 in. wide
or larger roll.
Cannot print as specified.
Lift the release lever and
replace paper with [ XXX ]
(vertical) or
larger.
Cannot print
as specified.
Lift the release
lever and replace
roll with 10 in.
wide or larger roll
Cannot print
as specified.
Replace paper with
[XXX] (vertical)
or larger.
The paper is too
small. Replace paper
with [XXX] (vertical) or
larger.
The paper is too
small. Replace roll
with 10 in. wide or
larger roll.
Cannot print as specified.
Lift the release lever and
replace paper with [XXX]
(vertical) or larger.
Cannot print as specified.
Lift the release lever and
replace roll with 10 in. wide
or larger roll.
2E20 Wrong paper type.
Lift the release
lever and reload
the paper.
Stop: Stop Printing
Wrong paper.
Lift the release
lever and replace
the paper.
Paper mismatch
Make sure media type
and paper size match
for the adjustment
print.
8-22
Panel display Panel display
(Large LCD) (Small LCD)
Roll Paper
Please Replace
Paper Not Loaded
Press (upper arrow) Key
Paper Jam
Press (upper arrow) Key
Remove paper
Cannot Feed
Press (upper arrow) Key
Paper Mismatch
ReplcPap:Press (lower
arrow)
Need A3 Vertical
or Larger
Press (lower arrow) Key
and Reload
Explanation/Detection sequence
No roll paper available (trailing edge of roll
paper detected)
-Trailing edge of paper has been detected
by paper sensor in a roll paper operation.
-LF out of synchronization on roll paper.
(Detected the spool no longer rotating.)
Jam while ejecting paper
(A sequence of removing jams with the
pinch roller released is required)
A jam has been detected while ejecting
paper.
Feeding error
LF out of synchronization for cut sheet
Paper mismatch (size)
The second and subsequent sheets of paper
have been fed as a paper size different from
the first sheet when adjustment was made
with cut sheet.
The paper size setting in effect at the start
of an internal print session has fallen below
the minimum size specified for that internal
print session.
[XXX x YYY]: Required minimum size
The second and subsequent sheets of paper
have been fed as a paper size different from
the first sheet when adjustment was made
with cut sheet.
[XXX x YYY]: Required minimum size
Paper mismatch (type) (on adjustment)
The second and subsequent sheets of paper
have been fed as a paper type different
from the first sheet when LF adjustment
was made from a cassette.
Remedial Action
1. Replace the roll paper.
2. Check paper sensor R (I/O mode).
3. Is the paper fed successfully (under
a negative load or any other
influence)?
1. Open and close the release lever to
reload the paper.
2. Remove the paper once
Refeed the paper.
Check the paper that is actually loaded
on the printer and the paper size setting
of the driver.
Equalize the paper types for the first
and second sheets with each other in
adjustment printing.
