Canon imagePROGRAF iPF815 Service Manual page 264

Chapter 7
5) EXCHANGE: Counters related to parts replacement
MTC EXC.
HEAD EXC.
BOARD EXC.(M/B)
UNIT A EXC.
UNIT D EXC.
UNIT H EXC.
UNIT K EXC.
UNIT M EXC.
UNIT P EXC.
UNIT S EXC.
UNIT T EXC.
UNIT V EXC.
UNIT Y EXC.
6) DETAIL-CNT: Other counters
MOVE PRINTER
N-INKCHK(XX)
MEDIACONFIG-CNT
7) INK-USE1: Counters related to ink consumption
INK-USE1(XX)
INK-USE1(TTL)
N-INK-USE1(XX)
N-INK-USE1(TTL)
8) INK-USE2: Counters related to ink consumption
INK-USE2(XX)
INK-USE2(TTL)
N-INK-USE2(XX)
N-INK-USE2(TTL)
9) INK-EXC: Counters related to ink tank replacement
INK-EXC(XX)
INK-EXC(TTL)
N-INK-EXC(XX)
N-INK-EXC(TTL)
7-12
Display
Maintenance cartridge replacement count
Printhead replacement count
Main controller PCB replacement count
Unit A (waste ink system) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS A])
Unit D (carriage unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS D])
Unit H (purge unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS H1])
Unit K (head management sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS K1])
Unit M (carriage unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS M1])
Unit P (feed motor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS P1])
Unit S (upper pick-up roller) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS S1])
Unit P (lower pick-up roller) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS T1])
Unit V (mist fan unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS V1])
Unit Y (cutter) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Y1])
Display
A(B,C,D,E) A: Number of times "MOVE PRINTER" on Main menu is executed
B: Number of times "LEVEL 1" is executed
C: Number of times "LEVEL 2" is executed
D: Number of times "LEVEL 3" is executed
E: "LEVEL" of previously executed "MOVE PRINTER"
XX: Ink color
Count of turning off the ink remaining level detection for each color
Count of media registered by media editor
Display
XX: Ink color
Cumulative consumption amount of generic ink
Total amount of cumulative consumption of generic ink
XX: Ink color
Cumulative consumption amount of refilled ink
Total amount of cumulative consumption of refilled ink
Display
XX: Ink color
Consumption amount of generic ink of the currently installed ink tank.
Total consumption amount of generic ink of the currently installed ink tanks
XX: Ink color
Consumption amount of refilled ink of the currently installed ink tank
Total consumption amount of refilled ink of the currently installed ink tanks
Display
XX: Ink color
Cumulative count of generic ink tank replacement
Total amount of cumulative count of generic ink tank replacement
XX: Ink color
Cumulative count of refilled ink tank replacement
Total amount of cumulative count of refilled ink tank replacement
Description
Description
Description
Description
Description
Unit
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Unit
Times
Times
Times
Unit
ml
ml
ml
ml
Unit
ml
ml
ml
ml
Unit
ml
ml
ml
ml
