Canon imagePROGRAF iPF815 Service Manual page 229

J3801
Pin Number Signal name
6 GND
7 RGV7(SNS5V2)
8 /KYUUSHI_SNS_R1
9 GND
10 RGV7(SNS5V2)
11 /YOUSHIHABA_SNS
12 GND
J4003
Pin Number Signal name
1 OUT_ZENMENM_B
2 OUT_ZENMENM_A
3 OUT_ZENMENM_BB
4 OUT_ZENMENM_AB
J3901
Pin Number Signal name
1 RGN19(VM_26V_2)
2 PICKUP_CL_OUT
3 RGN19(VM_26V_2)
4 KYUUSHI_CL_OUT
5 RGN19(VM_26V_2)
6 FLAPPER_SOL_OUT
7 RGN19(VM_26V_2)
8 PINCH_CL_OUT
9 RGV8(SNS3V)
10 GND
11 /PINCH_CLOSE_SNS
12 RGV8(SNS3V)
13 GND
14 /PINCH_OPEN_SNS
15 N.C
J3902
Pin Number Signal name
1 OUT_LENIP_BB
2 OUT_LENIP_B
3 OUT_LENIP_AB
4 OUT_LENIP_A
J3151
Pin Number Signal name
1 RGV16(VM32V)
2 RGV16(VM32V)
3 N.C
J4001
Pin Number Signal name
A1 GND
A2 LF_FNCA
A3 RGV29(UMF5V)
A4 LF_FNCB
A5 SNS3V(RGV18)
A6 GND
A7 /LF_HP
A8 GND
A9 SPOOL_ENCA
A10 RGV29(UMF5V)
IN/OUT Function
- GND
OUT Power supply(+5V)
Roll media pick-up roller paper detection sensor output signal
- GND
OUT Power supply(+5V)
Roll media width detection sensor output signal
- GND
T-6-17
IN/OUT Function
OUT Roll media pick-up motor drive signal B
OUT Roll media pick-up motor drive signal A
OUT Roll media pick-up motor drive signal BB
OUT Roll media pick-up motor drive signal AB
T-6-18
IN/OUT Function
OUT Power supply(+26V)
OUT Roll media pick-up cam clutch drive signal
OUT Power supply(+26V)
OUT Roll media pick-up roller clutch drive signal
OUT Power supply(+26V)
OUT Flapper solenoid drive signal
OUT Power supply(+26V)
OUT Pinch roller pressure clutch drive signal
OUT Power supply(+3V)
- GND
IN Pinch roller pressure detection sensor output signal
OUT Power supply(+3V)
- GND
IN Pinch roller release detection sensor output signal
- N.C
T-6-19
IN/OUT Function
OUT Pinch roller pressure motor drive signal BB
OUT Roll media pick-up motor drive signal B
OUT Roll media pick-up motor drive signal AB
OUT Roll media pick-up motor drive signal A
T-6-20
IN/OUT Function
OUT Power supply(+32V)
IN Upper cover lock switch output signal
- N.C
T-6-21
IN/OUT Function
- GND
IN Feed roller encoder output signal A
OUT Power supply(+5V)
IN Feed roller encoder output signal B
OUT Power supply(+3.3V)
- GND
IN Feed roller HP sensor output signal
- GND
- N.C
- N.C
Chapter 6
6-7
