Canon imagePROGRAF iPF815 Service Manual page 225

J1101
Pin Number Signal name
42 /CBE2
43 GND
44 /FRAME
45 /IRDY
46 /TRDY
47 /DEVSEL
48 GND
49 /STOP
50 /LOCK
51 /PERP
52 /SERR
53 PAR
54 /CBE1
55 GND
56 GND
57 AD15
58 AD14
59 AD13
60 AD12
61 GND
62 AD11
63 AD10
64 AD9
65 AD8
66 /CBE0
67 GND
68 AD7
69 AD6
70 AD5
71 AD4
72 GND
73 AD3
74 AD2
75 AD1
76 AD0
77 GND
78 HDD_LED
79 +5V
80 +5V
81 +5V
82 +3.3V
83 +3.3V
84 +3.3V
85 GND
86 GND
87 GND
88 GND
J1201
Pin Number Signal name
1 AGND2
2 TXP
3 TXN
4 AGND2
5 RXN
6 RXP
7 AGND2
J1202
Pin Number Signal name
1 HDD_LED
2 +5V
IN/OUT Function
OUT Bus command and byte enable signal
- GND
IN/OUT Cycle frame signal
IN/OUT Initiator ready signal
IN/OUT Target ready signal
IN/OUT Device select signal
- GND
IN/OUT Stop signal
IN/OUT Lock signal
IN/OUT Parity error signal
IN/OUT System error signal
IN/OUT Parity signal
IN/OUT Bus command and byte enable signal
- GND
- GND
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
- GND
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Bus command and byte enable signal
- GND
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
- GND
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
- GND
- N.C.
OUT Power supply(+5V)
OUT Power supply(+5V)
OUT Power supply(+5V)
OUT Power supply(+3.3V)
OUT Power supply(+3.3V)
OUT Power supply(+3.3V)
- GND
- GND
- GND
- GND
T-6-2
IN/OUT Function
- GND
OUT Transmission Data
OUT Transmission Data
- GND
IN Receive Data
IN Receive Data
- GND
T-6-3
IN/OUT Function
IN Access signal
IN Power supply(+5V)
