Code
Panel display
(last 4 digits)
(Large LCD)
201C Paper jam
Push the release
lever back.
201D Paper jam
Remove the paper
after cutting at the
top of feed slot. Push the
release
lever back.
201E Media Type not
compatible with
cassette.
Check Media Type.
Stop: Stop Printing
2405 Borderless printng
not possible.
Lift the release
lever and reload
the paper.
Online: Print
Bordless Printing
not possible. Lift
release lever and
reload the paper.
Bordless Printing
not possible. Lift
release lever and
reload the paper
Online: Not bordrlss
Stop: Stop Printing
Paper position not
suitable for
borderless printing
Borderless printng
not possible. Check
roll position.
Online: Print
Load/Eject: Change Paper
Borderless printng
not possible. Check
roll width and
spacers.
Online: Print
Load/Eject: Change Paper
2406 Borderless printng
not possible. Check paper
size setting.
Online: Print
Load/Eject: Change Paper
Borderless printng
not possible. Check
supported paper.
2407 Borderless printng
not possible. Paper
stretched or shrank.
Confirm usage cond.
of the paper.
2408 Borderless printng
not possible. Check
supported paper.
Bordless Printing
not possible. Lift
release lever and
reload the paper.
Panel display
Explanation/Detection sequence
(Small LCD)
While printing, paper width was detected
to have fluctuated beyond the predefined
value.
Failure of detecting right edge of the paper
(cut paper, in printing).
While printing, paper width was detected
to have fluctuated beyond the predefined
value.
Failure of detecting right edge of the paper
(cut paper, in printing).
Media Check Paper mismatch (cut sheet)
Please Cancel Cassette pickup has been specified for
Cas Cannot Feed paper that does not support cassette pickup.
Please Check
Roll Paper Chk Invalid paper loading position (borderless
Check Width/Spcr printing)
Borderless Prtng The position at which paper is loaded is
Not Possible unfit for borderless printing.
Data with a borderless print specification
has been received while the left or right
edge of roll paper was off the center of the
borderless print idle ejection port at the
completion of roll paper pickup.
Check Supported Borderless print data not printable (logic)
Paper. Borderless print data was received at the
No Borderless w/ start of printing and one or more of the
This Roll Paper following requirements are met at the same
time:
-A feeder slot other than one for roll paper
has been specified in the data.
-A paper type that does not support
borderless printing has been set on the data.
-Banner printing has been specified on the
data at the same time.
-A paper size that does not support
borderless printing has been specified in a
job for which paper had already been fed.
It occurs when all of the following
conditions are met at start of printing.
-Borderless printing data has been
received.
-Roll paper has been loaded, and its paper
width and edge position recognized at
loading are within the supported range of
borderless printing.
-As a result of right/left side edge detection
after start of print processing, it was
detected as beyond the supported range of
borderless printing.
At the start of borderless printing, roll
paper whose size doesn't support
borderless printing has been loaded.
Chapter 8
Remedial Action
By releasing the release lever, move to
the loading sequence, and load paper
to the correct position.
1. Cut the paper near the feed slot, and
remove the paper.
2. Release the release lever, and load
the paper to the correct position.
Check the cassette pick-up setting/
paper type.
Reload the roll paper.
Check spacers
Reset the driver and RIP.
Reset /replace the roll paper.
Confirm and explain usage
environment.
Replace with appropriate paper.
