10) MEDIA x (x: 1 to 7): Counters related to media
One to seven media types are displayed individually in order with large cumulative print area.
Display
NAME
TTL
TTL
ROLL UPPER
ROLL UPPER
ROLL LOWER
ROLL LOWER
CUT SHEET
CUT SHEET
11) MEDIA OTHER: Counters related to media
Displays the total amount of cumulative print area of the other media type than the above-mentioned
Display
NAME
TTL
TTL
ROLL UPPER
ROLL UPPER
ROLL LOWER
ROLL LOWER
CUT SHEET
CUT SHEET
12) MEDIASIZE1 ROLL: Counters related to roll media printing
Display
P-SQ 44-60
P-SQ 36-44
P-SQ 24-36
P-SQ 17-24
P-SQ -17
P-CNT 44-60
P-CNT 36-44
P-CNT 24-36
P-CNT 17-24
P-CNT -17
13) MEDIASIZE2 ROLL: Counters related to roll media printing
Display
D-SQ 44-60
D-SQ 36-44
D-SQ 24-36
D-SQ 17-24
D-SQ -17
D-CNT 44-60
D-CNT 36-44
D-CNT 24-36
D-CNT 17-24
D-CNT -17
Media type
Total amount of cumulative print area of roll media and cut sheet (metric)
Total amount of cumulative print area of roll media and cut sheet (inch)
Cumulative print area of upper roll media (metric)
Cumulative print area of upper roll media (inch)
Cumulative print area of lower roll media (metric)
Cumulative print area of lower roll media (inch)
Cumulative print area of cut sheet (metric)
Cumulative print area of cut sheet (inch)
Media type
Total amount of cumulative print area of roll media and cut sheet (metric)
Total amount of cumulative print area of roll media and cut sheet (inch)
Cumulative print area of upper roll media (metric)
Cumulative print area of upper roll media (inch)
Cumulative print area of lower roll media (metric)
Cumulative print area of lower roll media (inch)
Cumulative print area of cut sheet (metric)
Cumulative print area of cut sheet (inch)
Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (physical size)
Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (physical size)
Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (physical size)
Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (physical size)
Cumulative print area of paper less than 17 inches (physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper less than 17 inches (physical size)
Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (data size)
Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (data size)
Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size)
Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size)
Cumulative print area of paper less than 17 inches (data size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60
inches (data size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44
inches (data size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36
inches (data size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24
inches (data size)
Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size)
Description
Description
Description
Description
Chapter 7
Unit
-
m2
Sq.f
m2
Sq.f
m2
Sq.f
m2
Sq.f
Unit
-
m2
Sq.f
m2
Sq.f
m2
Sq.f
m2
Sq.f
Unit
m2/Sq.f
m2/Sq.f
m2/Sq.f
m2/Sq.f
m2/Sq.f
sheets
sheets
sheets
sheets
sheets
Unit
m2/Sq.f
m2/Sq.f
m2/Sq.f
m2/Sq.f
m2/Sq.f
sheets
sheets
sheets
sheets
sheets
