Figure 3-11-3: Expansion header J13 schematic
The figure 3-11-4 detailed the J13 expansion port on the carrier board. The
Pin1 and Pin2 of the expansion port are already marked on the board.
Figure 3-11-4: Expansion header J13 on the carrier board
J13 Expansion Header Pin Assignment
Pin Number
52 / 59
FPGA Pin Pin Number
