ARTIX-7 FPGA Development Board AX7A200 User Manual
Figure 3-5-1: HDMI Output on the Carrire Board
HDMI Input Pin Assignment:
Signal Name
9134_NRESET
9134_D[10]
9134_D[12]
9134_D[13]
9134_D[14]
9134_D[15]
9134_D[16]
42 / 59
9134_CLK
9134_HS
9134_VS
9134_DE
9134_D[0]
9134_D[1]
9134_D[2]
9134_D[3]
9134_D[4]
9134_D[5]
9134_D[6]
9134_D[7]
9134_D[8]
9134_D[9]
9134_D[11]
Amazon Store:
Sales Email:
FPGA Pin
Y17
Y22
T18
R18
U22
V22
Y18
Y19
W19
W20
Y21
U21
T21
W21
W22
T20
AB18
AA18
AA19
AB20
AA20
AA21
