ARTIX-7 FPGA Development Board AX7A200 User Manual
9134_D[17]
9134_D[18]
9134_D[19]
9134_D[20]
9134_D[21]
9134_D[22]
9134_D[23]
HDMI_SCL

Part 3.6: HDMI Input interface

HDMI output interface, select Silion Image's SIL9013/9011 HDMI decoder
chip, support up to 1080P@60Hz input and support data output in different
formats.
The IIC configuration interface of the SIL9013/9011 is connected to the IO
of the FPGA. The SIL9013 is initialized and controlled through FPGA
programming. The hardware connection of the HDMI input interface is shown in
Figure 3-6-1.
43 / 59
HDMI_SDA
Figure 3-6-1: HDMI Input Schematic
Amazon Store:
Sales Email:
AB22
AB21
W17
V17
V20
U20
V19
H13
G13
