Part 3: Carrier Board

Part 3.1: Carrier Board Introduction

Through the previous function introduction, you can understand the
function of the carrier board part
 1-channel PCIe x2 high speed data transmission interface
 2-Port SPF cage
 1-channel HDMI video input interface
 1-channel HDMI video Output interface
 1-channel 10/100M/1000M Ethernet RJ-45 interface
 1-channel USB-to-Uart Bridge Communication interface
 1 SD Card Slot
 EEPROM
 2-channel 40-pin expansion ports
 JTAG debugging interface
 5 independent buttons
 4 user LED lights
