ARTIX-7 FPGA Development Board AX7A200 User Manual
PIN33 B15_L5_N
PIN35 B15_L3_N
PIN37 B15_L3_P
PIN39 GND
PIN41 B15_L19_P
PIN43 B15_L19_N
PIN45 B15_L20_P
PIN47 B15_L20_N
PIN49 GND
PIN51 B15_L14_P
PIN53 B15_L14_N
PIN55 B15_L21_P
PIN57 B15_L21_N
PIN59 GND
PIN61 B15_L23_P
PIN63 B15_L23_N
PIN65 B15_L22_P
PIN67 B15_L22_N
PIN69 GND
PIN71 B15_L24_P
PIN73 B15_L24_N
PIN75 NC
PIN77 FPGA_TCK
PIN79 FPGA_TDO
Figure 2-9-3: Board to Board Connectors CON3 on the Core Board
29 / 59
H15 3.3V PIN34
H14 3.3V PIN36
J14 3.3V PIN38
- Ground PIN40
K13 3.3V PIN42
K14 3.3V PIN44
M13 3.3V PIN46
L13 3.3V PIN48
- Ground PIN50
L19 3.3V PIN52
L20 3.3V PIN54
K17 3.3V PIN56
J17 3.3V PIN58
- Ground PIN60
L16 3.3V PIN62
K16 3.3V PIN64
L14 3.3V PIN66
L15 3.3V PIN68
- Ground PIN70
M15 3.3V PIN72
M16 3.3V PIN74
- PIN76
V12 3.3V PIN78
U13 3.3V PIN80
Amazon Store:
Sales Email: rachel.zhou@aithtech.com
B15_L7_P
B15_L9_P
B15_L9_N
GND
B15_L15_N
B15_L15_P
B15_L6_N
B15_L6_P
GND
B15_L13_N
B15_L13_P
B15_L10_P
B15_L10_N
GND
B15_L18_P
B15_L18_N
B15_L17_N
B15_L17_P
GND
B15_L16_P
B15_L16_N
NC
FPGA_TDI
FPGA_TMS
https://www.amazon.com/alinx
J22 3.3V
K21 3.3V
K22 3.3V
- Ground
M22 3.3V
N22 3.3V
H18 3.3V
H17 3.3V
- Ground
K19 3.3V
K18 3.3V
M21 3.3V
L21 3.3V
- Ground
N20 3.3V
M20 3.3V
N19 3.3V
N18 3.3V
- Ground
M18 3.3V
L18 3.3V
-
R13 3.3V
T13 3.3V
