ARTIX-7 FPGA Development Board AX7A200 User Manual
Figure 3-6-2: HDMI Input on the Carrier Board
HDMI Input Pin Assignment:
Signal Name
9013_NRESET
9013_D[10]
9013_D[12]
9013_D[13]
9013_D[14]
9013_D[15]
44 / 59
9013_CLK
9013_HS
9013_VS
9013_DE
9013_D[0]
9013_D[1]
9013_D[2]
9013_D[3]
9013_D[4]
9013_D[5]
9013_D[6]
9013_D[7]
9013_D[8]
9013_D[9]
9013_D[11]
Amazon Store:
Sales Email:
FPG Pin Number
J21
K18
N18
M18
N19
M20
N20
L21
M21
K19
H17
H18
N22
M22
K22
K21
J22
H22
H20
G20
M17
