ARTIX-7 FPGA Development Board AX7A200 User Manual
QSPI Flash pin assignments:
Net Name
QSPI_CLK
QSPI_CS
QSPI_DQ0
QSPI_DQ1
QSPI_DQ2
QSPI_DQ3
Figure 2-5-1: QSPI FLASH on the Core Board
20 / 59
Figure 2-5-1: QSPI Flash Schematic
FPGA PIN Name
IO_L6P_T0_FCS_B_14
IO_L1P_T0_D00_MOSI_14
IO_L1N_T0_D01_DIN_14
IO_L2P_T0_D02_14
IO_L2N_T0_D03_14
Amazon Store:
Sales Email:
CCLK_0
https://www.amazon.com/alinx
rachel.zhou@aithtech.com
FPGA P/N
L12
T19
P22
R22
P21
R21
